23
11.2. Basic Setting Operation
11.2.1. Entering the setting mode (matrix mode only)
Holding down the Utility menu key for 2 seconds or more displays the setting menu screen.
11.2.2. Setting screen operation examples
[Moving the setting screen or setting item]
Use the Screen shift key mainly. (The Enter and ESC/BACK keys may also be used.)
Normal operation mode
I N P U T – S E T T I N G
Setting menu screen
UTILITY
S E L E C T I N P U T C H I N P U T – S E T T I N G
I N 1 – P H A N T O M – O F F
When moving the setting screen:
• Examples of using the Left and Right shift keys
• Example of using the Up and Down shift keys
I N 1 – I N P U T 1
H P F – 4 0 0 H Z L P F – 1 2 . 5 H P F – 4 0 0 H Z L P F – 1 2 . 5
When moving the setting item on the same screen:
Flashes
