Tascam CD-302 - Manual (Page 31)

TASCAM CD-302
31
5 - Specifications and reference
5.1 Specifications
The following values are applicable when the key and
tempo values are set to 0:
5.1.1 Dimensions
Disc types 8 cm/12 cm CD
Number of channels 2 channel
Resolution 16-bit
Sampling frequency 44.1 kHz
DA conversion 16-bit, 8x oversampling
Output impedance < 1 k
Ω
Maximum output level +6 dBV
Voltage requirements USA/Canada 120 VAC, 60 Hz
U.K./Europe 230 VAC, 50 Hz
Australia 240 VAC, 50 Hz
Power consumption 32 W
Applicable electromagnetic
environment E4
Peak inrush current 0.8 A
Dimensions w x h x d
(main unit — 2U)
(remote control units – 5U)
482 x 88 x 261 (mm)
19 x 3.5 x 10.3 (in)
482 x 220 x 87 (mm)
19 x 8.7 x 3.4 (in)
Weight (main unit)
(remote control units) 5.9 kg (13 lbs)
3.9 kg (6.6 lbs)
Frequency response 20 Hz — 20 kHz ± 1.0 dB
Dynamic range > 98 dB
S/N ratio > 98 dB (IHF-A)
Total harmonic distortion < 0.006%
482mm (19.0")
482mm (19.0")
76mm (3.0") 88mm (3.5)
105mm
(4.1")
220mm (8.7")
102mm (4.0")
465mm (18.3")
466mm (18.3")
3.5mm (0.14") 9.2mm (0.4") 261mm (10.3")
431mm (17.0")
431mm (17.0")
146mm (5.75")
87mm (3.4") 57mm (2.25")
