ROUTINE MAINTENANCE
57
6
CLEANING THE TRANSFER CHARGER
If copies start becoming streaky or blotchy, the transfer charger may be dirty.
Clean the charger using the following procedure.
1 Turn the power switch off.
2 Open the bypass tray and the side
cover.
3 Lift and pull out the upper paper tray.
4 Take the charger cleaner out by
holding the tab.
5 Set the charger cleaner onto the
transfer charger and gently slide the
cleaner in the direction indicated by
the arrow two or three times.
If the white sheet metal is
smudged with toner, wipe
it with a soft, clean cloth.
6 Return the charger cleaner to its
original position. Close the upper
paper tray. Close the side cover by
pressing the handle on the cover.
7 Turn the power switch on.
Charger
cleaner
Slide the charger cleaner from one end to
the other end along the groove of the
transfer charger. If the cleaner is stopped on
the way, smudges on copies may occur.
Note
