APPENDIX 1 SPECIFICATIONS ENGLISH VERSION
A1.2 Options
EA1- 2
A1.2 Options
Option Name Type Description
Keyboard display unit KB-75-QM This module is an external intelligent keyboard
display unit.
Cutter module B-SV204-QM
B-SV404-QM
A cutter unit that makes stub cuts
A cutter unit that makes normal cuts.
Strip sensor B-SV904-H-QM When attached to the front of the Media Outlet, this
sensor allows the on-demand strip issue by
detecting the presence or lack of a label.
Memory module B-SV704-E1M-QM (1MB)
B-SV704-E2M-QM (2MB)
B-SV704-E3M-QM (3MB)
B-SV704-E4M-QM (4MB)
B-SV704-E6M-QM (6MB)
B-SV704-E8M-QM (8MB)
A flash ROM memory PC board
External media roll hanger B-SV904-PH-QM When this option is attached to the printer, a media
roll with an outer roll diameter exceeding 127 mm
(5”) can be used.
Linerless paper printing
kit
B-SV904-LP-QM This kit consists of a platen and a sheet which
prevent the linerless paper from sticking to the
printer inside.
LAN adapter B-SV704-LAN-QQ
(For AC100 to 120V)
B-SV704-LAN-QP
(For AC200 to 240V)
This option enables the printer to be used in a LAN
network.
A1.3 Media
Please make sure that the media to be used is approved by TOSHIBA TEC. The warranties do not apply to
problems caused by using media that is not approved by TOSHIBA TEC.
For information regarding TOSHIBA TEC-approved media, please contact a TOSHIBA TEC authorised
representative.
A1.3.1 Media Type
Two types of media can be loaded for this thermal transfer and direct thermal printer: label or tag. The table
below shows the size and shape of the media that can be used on this printer.
NOTE:
The above options are available from your nearest TOSHIBA TEC representative or TOSHIBA TEC Head Quarters.
Feed Direction
Black Mark
(on reverse side)
Tag paper
Cut position
Black Mark
(on reverse side)
Label
