APPENDIX 1 SPECIFICATIONS ENGLISH VERSION
A1.1 Printer
EA1- 1
APPENDIX 1 SPECIFICATIONS
Appendix 1 describes the printer specifications and supplies for use on the B-SV4T printer.
A1.1 Printer
The following are the printer specifications.
Item Specifications
AC100 to 240V, 50/60 Hz
100 to 120V: 2.1A, 49.0W maximum, 200 to 240V: 2.1A, 49.9W maximum
100 to 120V: 0.13A, 4.0W maximum, 200 to 240V: 0.16A, 3.8 W maximum
Supply voltage
Power consumption
During a print job
During standby
Power supply
Operating temperature range
Storage temperature range
Relative humidity
Humidity for storage
Ventilation for storage
Resolution
Printing method
Issue mode
Printing speed
In the batch/cut mode
In the strip mode
Available media width
(including backing paper)
Effective print width (max.)
Dimension (W × D × H)
Weight
Available bar code types
Available two-dimensional code
Available bar code font
Rotations
Standard interface
100 to 240V universal switching power supply
5 °C to 40°C (40°F to 104°F)
-40 °C to 60°C
25% to 85% RH (no condensation)
10% to 90% RH (no condensation)
Free air environment
203 dpi
Thermal transfer and Direct thermal
Batch, Strip, Cut
50.8 mm/sec. (2”/sec.), 76.2 mm/sec. (3”/sec.), 101.6 mm/sec. (4”/sec.),
127 mm/sec. (5”/sec.)
50.8 mm/sec. (2”/sec.), 76.2 mm/sec. (3”/sec.)
25.4 mm (1.0”) to 112 mm (4.4”)
108.0 mm (4.3”)
213.0 mm × 314.0 mm × 188.0 mm (8.4” Ч 12.4” Ч 7.4”)
2.8 kg (6.2 lb) (Excluding Media)
EAN8, EAN13, EAN128, EAN and UPC 2(5) digital add-on, UPC-A, UPC-E,
MSI, Interleaved 2 of 5, CODE39, CODE39C, CODE93, CODE128UCC,
CODE128 Subsets A.B.C, CODE11, CODABAR, POSTNET, PLESSEY,
Reduced space Symbology
Data Matrix, PDF417, QR code, Maxi Code, Micro PDF417
Times Roman (14 point), Helvetica (12 point), Presentation (18 point), Letter
Gothic (9.5 pint), Courier (10 point), Prestige Elite (7 point), Outline font (1
type)
0 °, 90°, 180°, 270°
Serial interface (RS-232C)
Parallel interface (Centronics)
USB (V1.1)
Optional interface LAN Adapter
NOTES:
• Data Matrix
TM is a trademark of International Data Matrix Inc., U.S.
• PDF417 TM is a trademark of Symbol Technologies Inc., US.
• QR Code is a trademark of DENSO CORPORATION.
• Maxi Code is a trademark of United Parcel Service of America, Inc., U.S.
