2. PRINTER SETUP ENGLISH VERSION
2.8 Media Sensor Calibration, Self Print Test, and Dump Mode Utilities
2.8.2 Self Print Test and
Dump Mode (Cont.)
Print test label sample
PRINTER INFO.
PROGRAM VERSION
VX.XX XXXX
TONE ADJUST +XX
FEED ADJUST +XX.Xmm
CUT POSITION ADJUST +XX.Xmm
BACKFEED ADJUST +XX.Xmm
PARAMETER [PC-850][0]
[9600][8][1][NONE][0]
[ON][AUTO][FEED][B0]
X-COORDINATE ADJUST
+XX.Xmm
SENSOR TRANSMISSIVE [17]
MEMORY [192KB][XXXKB]
TTF AREA
[XXXKB][XXXKB]
EXT CHAR AREA [XXXKB][XXXKB]
BASIC AREA [XXXKB][XXXKB]
PC SAVE AREA [XXXKB][XXXKB]
INFORMATION XXXXXXXXXXXXXXXXXXX
TOTAL FEED
X.XXKm
NOTE:
The following commands should
not affect the test print issue.
D, AX, XS, Z2;1, Z2;2 (without
AY)
The test print contents should be changed by the following commands
and parameters:
PROGRAM VERSION: VX.XX XXXX --- Firmware version and checksum
TONE ADJUST: +XX ------------------------- Print tone fine adjustment value
FEED ADJUST: +XX.Xmm ------------------ Print position fine adjustment value
CUT POSITION ADJUST: +XX.Xmm ----- Cut position fine adjustment value
BACKFEED ADJUST: +XX.Xmm ---------- Back feed amount fine adjustment value
PARAMETER: [PC-850][0] ----------------- Character code selection and Font “0”
selection
[9600][8][1][NONE][0] Baud rate, Data length, Stop bit length,
Parity, and Transmission control of RS-
232C
[ON][AUTO][FEED][B0] Forward feed wait function, Control code,
Feed key function, and Euro code
X-COORDINTE ADJUST: +XX.Xmm ----- X-coordinate fine adjustment value
SENSOR: TRANSMISSIVE [17] ------------ Sensor selection and sensitivity
MEMORY: [192KB][XXXKB]--------------- Memory capacity of the Main PC Board and
optional memory card (0,1,2,3,4,6,8)
TTF AREA: [XXXKB][XXXKB]------------ True type font storage area, Main PC board
and optional memory card
EXT CHAR AREA: [XXXKB][XXXKB] -- Writable character storage area, Main PC
board and optional memory card
BASIC AREA: [XXXKB][XXXKB] -------- BASIC file storage area, Main PC board and
optional memory card
PC SAVE AREA: [XXXKB][XXXKB] ----- PC save storage area, Main PC board and
optional memory card
INFORMATION: ------------------------------- Printed only when some information is
stored in the flash ROM
TOTAL FEED ----------------------------------- Total feed distance
