8. SPECIFICATIONS
* Applies to the system where the unit and Combination camera are connected in a matched pair. Represents
the total of connected cable distances if multiple Combination cameras or Interface units are connected in
the system (when the CPEV-S cable thicker than 0.65 mm in diameter is used).
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
D-sub connector (9 pins, male) .................. 1
D-sub connector (25 pins, male) ................ 1
Power Source 12 V DC (AC adapter)
Current Consumption 150 mA
Slave Remote Controller RS-485, screwless connector
Camera Control RS-485, screwless connector
Switcher Control RS-485, screwless connector
RS-232C, D-sub connector (9 pins, male)
Alarm Input RS-232C, D-sub connector (9 pins, male)
Alarm Output / Control Input Alarm output: 16 channels, NPN open collector output,
withstand voltage: 30 V DC, control current: 20 mA
Alarm input: 1 channel, no-voltage make contact input,
open coltage: 5 V DC, short-circuit current: 5 mA max.
Home position selection input: 1 channel, no-voltage make contact input,
open voltage: 5 V DC,
short-circuit current: 5 mA max.
D-sub connector (25 pins, female)
Display LED indication of control status, alarm status, alarm hold status,
still picture status, defroster, auxiliary setting, auto panning, and lens speed
LCD indication of key entry confirmation
Alarm Signal Continuous alarm tone (can be turned on and off)
Number of Unit Connections Up to 2 (one to be set for MASTER unit, another for SLAVE unit)
Maximum Cable Distance 1.2 km* (between the Remote controller and the Combination cameras)
Operating Temperature 0 to +50°C
Operating Humidity Under 90% (no due condensation produced)
Finish Panel: Surface-treated steel plate, sand gray, paint
Sides: Rubber
Dimensions 326 (w) x 62 (h) x 185.2 (d) mm
Weight 1.8 kg (AC adapter excluded)
Note
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Modifications
Any modifications made to this device that are not approved by TOA Corporation may void the authority
granted to the user by the FCC to operate this equipment.
C-RM500 complies with Part 15 of the FCC Rules.
