1.4 System View
Front View
Ref Component Description
ΠPower Button Turns the power on and off (soft-off).
•
Power Indicator Glows green when the power is on.
Ž LAN1 Indicator Indicates an active network connection on LAN1 (external connection).
•
LAN2 Indicator Indicates an active network connection on LAN2 (internal connection).
• Hard Disk Drive
Indicator Indicates activity on the hard disk drive.
‘
LCD Screen Displays messages and values entered.
’ Control Buttons Allow you to enter network configuration information, reboot the system,
and power down the system.
