Tyan Computer Transport GT24 B2891 User Manual
Tyan Computer Hardware
Table of contents
Document Outline
- Chapter1Overview.pdf
- Chapter2Setting Up.pdf
- Chapter 2: Setting Up
- 2.0.1 Before You Begin
- 2.0.2 Work Area
- 2.0.3 Tools
- 2.0.4 Precautions
- 2.1 Rack Mounting
- 2.1.1 Installing the Server in a Rack
- 1. Screw the mounting ear to each side of Transport GT24 as shown using 2 screws from the supplied screws kit.
- 2. Screw the sliding rail brackets to the sliding rails.
- 3. Slide the sliding rail to each side of the Transport GT24.
- 4. Screw the sliding rail to each side using 2 screws as shown.
- 5. Locate the mounting bracket from the supplied kit and screw it to the rack using 2 screws on each side. Be careful that the m...
- 6. Lift and insert the unit into place in the rack (A). Ensure the unit is completely inserted into the rack (B). Then screw the unit into place as shown (C).
- 2.1.1 Installing the Server in a Rack
- 2.2 Installing Motherboard Components
- 2.2.1 Removing the Chassis Cover
- 2.2.2 Installing the CPU, Heatsink and Air Duct
- 1. After removing the pre-installed air duct, locate the CPU sockets.
- CPU socket
- 2. Pull the CPU lever up to unlock the CPU socket.
- 3. Place the CPU in the CPU socket, ensuring that pin 1 is located as shown in the following illustration.
- 4. Press the CPU socket lever down in the direction shown to secure the CPU.
- 5. Align the heatsink screw holes with the holes on the motherboard and insert two heatsink screws as shown.
- 6. Replace the air duct over the heatsink and secure it to the motherboard using two screws.
- 2.2.3 Installing the Memory
- 2.2.4 Installing a PCI Card
- 2.3 Installing the Hard Drive for B2891G24S4H/B2891G24U4H
- 1. Press the locking lever latch in the direction of arrow (A) and then pull the locking lever open (B).
- 2. Slide the drive tray out.
- 3. Place a hard drive into the drive tray.
- 4. Using 4 HDD screws to secure the HDD.
- 5. Reinsert the drive tray into the chassis (A), ensuring that the drive tray is completely inserted into the chassis (B).
- 6. Pressing the locking lever to secure the hard drive tray.
- 2.4 Installing the Hard Drive for B2891G24S4-LC
- 2.5 Installing the Slim FDD (Option)
- 1. Locate the two FDD rails and screws from the FDD kit. Secure the two rails to FDD using four screws.
- 2. Connect the FDD backplane to FDD using 2 screws.
- 3. Connect the FFC cable to FDD.
- 4. Using a screw driver to pull open the door of FDD tray.
- 5. Insert FDD module into the tray.
- 6. Locate the FDD cable from FDD kit. Connect the wrinkle side to the connector on floppy slot. Refer to the picture below for the correct direction. Then, connect the power cable of FDD to the connector on floppy slot.
- 7. Connect the other side to the connector on motherboard.
- Chapter 2: Setting Up
- Chapter3Replacing.pdf
- Chapter 3: Replacing Pre-Installed Components
- 3.1 Introduction
- 3.2 Disassembly Flowchart
- 3.3 Removing the Cover
- 3.4 Replacing Motherboard Components
- 3.5 Replacing the Slim CD-ROM
- 1. Remove the power and data cables from the slim CD- ROM adapter.
- 2. Press the latch in the direction as show to release the CD-ROM drive.
- 3. The CD-ROM drive will be freed from the drive bay after pressing the latch.
- 4. Remove the two screws that secure the CD-ROM drive to the bracket.
- 5. Replace the CD-ROM drive.
- 6. Use the two screws to secure the CD-ROM to the bracket. Then replace the unit into the drive bay and connect the CD-ROM power and data cables.
- 3.6 Replacing the LED Control Board
- 1. Remove the 2 screws securing the LED control board to the chassis.
- 2. Pull the LED control board free from the chassis as shown below.
- 3. Unplug the front panel ribbon cable from the connector.
- 4. Unplug the USB cable from the connector.
- 5. Remove the three screws securing the LED control board to the bracket
- 6. Release the LED control board from the chassis. After replacement, insert and secure the unit to the chassis following the reverse procedures from step 1~5.
- 3.7 Replacing the M1010 Adapter Board
- 1. Remove all the cables connected to the adapter board, including front panel, USB, LAN, power and five fan cables.
- 2. Remove the five screws to release the adapter board. Refer to page 47 for the locations..
- 3.7.1 M1010 Adapter Board Features
- 3.7.2 System Fan Layout
- 3.7.3 M1010 Adapter Board Connector Pin Definition
- 3.8 Replacing the SATA or SCSI Backplane
- 1. Remove the 3 screws securing the adapter board to the chassis.
- 2. Grab the two lables to lift the adapter board.
- 3. Remove the ten screws that secure the bracket to the adapter board.
- 4. Release the adapter board free from the bracket.
- 5. Replace the unit to the chassis following the reverse procedures from step 1 to 4 after done.
- 3.8.1 S-ATA Backplane (M1204) Features
- 3.8.2 SCSI Backplane (M1205) Features
- 3.9 Replacing the Power Supply
- Chapter 3: Replacing Pre-Installed Components
- Appendix.pdf
- Appendix I: BIOS Differences
- Appendix II: Cable Connection Tables
- Table 1: B2891G24S4H Model
- Table 2: B2891G24S4-LC Model
- Table 3: B2891G24U4H
- Table 4: System Fan to M1010 Adapter Board
- Table 5: M1010 Adapter Board to Motherboard
- Table 6: Power Supply to Motherboard
- Table 7: Power Supply to M1010 Adapter Board
- Table 8: Power Supply to M1204/M1205 HDD Backplane
- Table 9: M1010 Adapter Board to Motherboard
- Table 10: M1003 Front Panel Control Board Related Cable
- Table 11: CD-ROM Related Cable
- Table 12: Chassis Intrusion Cable
- Table 13: FDD Related Cable (Option)
- Technical Support
- Appendix II: Cable Connection Tables
- Appendix I: BIOS Differences
