4100U cabinets are available in one-, two-, and three-bay sizes. Each can be equipped
with a solid or perspex door. This chapter describes how to mount all types of 4100U
cabinets to a wall, and how to mount system card bays into the cabinets, modules to bays,
etc.
FACPs are assembled to order within the factory. Steps 2 to 6 below are therefore not
typically required in the field, but are included in case of in-field system expansion.
The section Introduction to FACPs describes the various components that make up the
FACP.
The assembly drawings 1976-136, 1976-137 are included in the appendix of this manual
for reference.
Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Introduction to FACPs (4100U)
2-2
Step 1. Mounting Cabinets (4100U) 2-9
Step 2. Mounting Card Bays to Cabinets (4100U) 2-9
Step 3. Configuring Cards (4100U) 2-10
Step 4. Interconnecting Modules and Bays 2-11
Step 5. Installing Modules into Expansion Bays (4100U)
2-15
Step 6. Installing LED/Switch Modules into Expansion Bays
(4100U) 2-20
The Terminal Block Utility Module (4100U) 2-27
