Tote Vision LCD-841SDI - Manual (Page 21)

• For color and B/W applications
• Active matrix technology allows wide viewing angle
• Acitve matrix technology eliminates distortion
• A/C adaptor included
• Response Time: 20ms/30ms (rising/falling)
• Built-in interface for wall or arm mounting
VESA 75mm FPMPMI compliant
MB-3 Desk stand (shown above)
HM-400 Under-cabinet hinge mount
Optional Accessories
Touchscreen: For 8.4" order LCD-840TS
For 6.4"order LCD-641TS
LCD-840 series: 8.4" TFT LCD active matrix
LCD-641 series: 6.4" TFT LCD active matrix
NTSC/PAL(auto sensing), S-Video, Analog RGB
LCD-840 series: 800(H) x 600(V) dots
LCD-641 series: 640(H) x 480(V) dots
LCD-840 series: 150 cd/m²(Nit)
LCD-641 series: 350 cd/m²(Nit)
LCD-840 series: 200:1, LCD-641 series: 150:1
LCD-840 series: 45/45/35/15
LCD-641 series: 55/55/35/15
Regulated 12 VDC, 3A (LCD-641V: Regulated 12 VDC, 2A)
LCD-840 series: 30 W (max)
LCD-641 series: 8 W (max)
1.0 V P-P (positive) 75 Ohm
LCD-840D: 19" x 7" (Occupies 4 RU) x 1.75"
LCD-840V: 264 x 163 x 38mm / 10.4" x 6.4" x 1.5"
LCD-641V: 225 x 133 x 41mm / 8.9" x 5.2" x 1.6"
LCD-641VL: 272 x 213.5 x 37.5mm / 11" x 8.4" x 1.6"
LCD-840 series: 174 x 131mm / 6.9" x 5.2"
LCD-641 series: 129 x 97mm / 5.1" x 3.8"
50 ~ 104°F or 10 ~ 40°C
RCA video IN, S-Video,
BNC video IN/OUT,
2.1 DC IN jacks,
15-pin mini D-sub (female)
LCD-840D: Net: 2.5 kg. / 5.6 lbs. Gross: 5.4 kg. / 12 lbs.
LCD-840V: Net: 3.2 kg. / 5.4 lbs. Gross: 3.6 kg. / 8 lbs.
LCD-840VL: Net: Est. 2.9 kg. / 6.4 lbs. Gross: 4.1 kg. / 9 lbs.
LCD-641V: Net: 1.4 kg. / 3 lbs. Gross: 2.7 kg. / 6 lbs. Display:
Input Signal:
Resolution:
Brightness rating:
Contrast Ratio:
Viewing angle L/R/T/B:
Power Requirements:
Power Consumption:
Video Input Level:
Dimensions (WHD):
Actual visible screen size (WH):
Operating temperature:
Connections:
Weight:
Active Matrix 8.4" and 6.4" Color LCD Monitors with PC Capabil ity
The Biggest Thing in
Little PC Capable
LCD Monitors
LCD-840D
LCD-840V
LCD-840VL
LCD-641V
LCD-641VL
1319 Dexter Ave. N. • Ste. 020 • Seattle, WA 98109
Tel: 206-623-6000 • FAX: 206-623-6609
Email: [email protected]
http://www.totevision.com
LCD-641V
In Metal Case
LCD-840VL
Flush Mount Unit
LCD-641VL
Flush Mount Unit
LCD-840D Rack Mount Unit
Shown with
optional MB-3
desk stand In Metal Case
Specifications subject to change without notice 30K
Available through:
©2008 ToteVision
P.21
LCD-840VL 8.4" Unit in Flush Mount Kit
Dimensions (WHD): 290 x 213 x 40.6mm / 11.4" x 8.4" x 1.6"
Installer’s Cut-out (WH): 229 x 175mm / 9" x 6.9"
Weight: Net: Est. 1.8 kg. / 4 lbs. Gross: Est. 2.7 kg. / 6 lbs.
LCD-641V 6.4" in Metal Case
LCD-641VL 6.4" Unit in Flush Mount Kit
Dimensions (WHD): 272 x 213.5 x 37.5mm / 11" x 8.4" x 1.5"
Installer’s Cut-out (WH): 227 x 172mm / 9" x 6.9"
Weight: Net: 1.8 kg. / 4 lbs. Gross: 2.7 kg. / 6 lbs.
(Bulk Special Order Only)
(Bulk Special Order Only)
(Bulk Special Order Only) (Bulk Special Order Only)
