Display:
Back Light:
Input Signal:
Resolution:
PC compatibility:
Dot Pitch:
Brightness rating:
Colors:
Contrast Ratio:
Number of Pixels:
Viewing angle L/R/T/B:
Pixel Configuration:
Input Signal Level:
Speakers:
Stereo Amplifier:
LCD-1700V: Dimensions w/o desk stand (WHD):
LCD-1700V: Dimensions w/ desk stand (WHD):
LCD-1700VR: Dimensions (WHD):
LCD-1703VRZ: Dimensions (WHD):
Actual visible screen size (WH):
Operating temperature:
Power Requirement:
Power Consumption:
Includes switching power supply:
Rear Terminal Connections:
LCD-1700V: Weight:
LCD-1700VR: Weight:
LCD-1703VRZ: Weight:
17.0" TFT LCD active matrix
Built-in (CCFT)
Composite NTSC/PAL (auto switching),
S-Video, component, DVI, Analog RGB
SXGA 1280(H) x 1024(V)dots
IBM / MAC compatible
0.264(H) x 0.264(V)mm
350 cd/m² (Nit)
16.7M
500:1
1,310,720 dots
85/85/85/85 degrees
Stripe
1.0V P-P (positive) 75 Ohm
8 ohms, 2W, 28 x 40mm oval type x 2
2 W x 2 @ 10% THD, 100 mV
426 x 376 x 67mm / 16.8" x 14.8" x 2.6"
426 x 432 x 162mm / 16.8" x 17" x 6.4"
19" x 14" x 2.5"
19" x 1.75" x 24"
338 x 270 mm / 13.3" x 10.6"
50~104°F or 10~40°C
Regulated 12VDC, 4A, negative ground
Part No. DC-1500 required for use in vehicles
LCD-1700V: 45 W (max), 3 W (power saving off mode)
LCD-1700VR/ 1703VRZ: 48 W (max),
3 W (power saving off mode)
100 ~ 240VAC (auto-sensing), 50 ~ 60Hz, 1.2A
BNC video IN/OUT jacks, 3.5 stereo audio IN jack,
RCA video IN, RCA L/R audio IN
2.1mm DC IN jack, S-Video jack
DVI (22 pin) w/ DVI /VGA cable
3.5 mm RS-232 IN, 9-pin component IN
Net: 7.3 kg./ 16 lbs. Gross: 9.5 kg. / 21 lbs.
Net: Est.7.4 kg./ 16.4 lbs Gross: 9.7 kg. / 21.4 lbs.
Net: 14.4 kg. / 13.8 lbs. Gross: 9.5 kg. / 21 lbs.
LCD-1700V
LCD-1700VR
LCD-1703VRZ
Active Matrix 17" Color LCD Monitors
• LCD -1703VRZ, 17" LCD color monitor in standard 19" rack mount kit
• Occupies 1 Rack Unit
• Monitor automatically turns ON/OFF when tilted up/down
• Rear mounting bracket extends from 24" to 30"
The Biggest Thing in
LCD Monitors
1319 Dexter Ave. N.• Ste. 020 • Seattle, WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
E-mail: [email protected]
http://www.totevision.com
DC-1500 Factory approved car cord
HM-400 Under-cabinet hinge mount
WM-30 Wall mount bracket (fixed)
WM-302 Wall mount with swing arm & 4-way adjustable
WMC-1720 Ceiling mount
Optional Accessories
HM-400 WM-302
Touch Screen: order LCD-1700TS for model LCD-1700V
Touch screen not available for model LCD-1703VRZ
Specifications subject to change without notice 60K ©2008 ToteVision
P.12
LCD-1700V
Occupies 1 RU
• Hot key allows toggeling between video, S-Video, component, PC modes
• PIP: Picture in picture capability with front toggel key
• On-screen display for: brightness, contrast, back light, hue, volume
• Front control keys for power, menu, auto, +/-, up/down
• For color and B&W applications
• Low power consumption
• Case made of durable ABS plastic
• Active matrix technology allows wide viewing angle
• Active matrix technology eliminates distortion
• LCD-1700V includes built-in removable desk stand
• LCD-1700V has built-in interface for wall or wall
mounting VESA 100mm FPMPMI compliant
• Response Time: 35/20ms (rising/falling)
• RS-232 feature allows external devices to
control the monitor through the serial port.
LCD-1703VRZ
in 19" 1 RU Rack Mount
LCD-1700VR
in 19" Rack Mount Kit
Occupies 8 RU
with
DVI
with
DVI
