Tote Vision LCD-4700HD - Manual

Display:
Back Light:
Input Signal:
PC compatibility:
Dot Pitch:
Colors:
Number of Pixels:
Response Time:
Audio output:
Speakers (separate):
Viewing angle L/R/T/B:
Pixel Configuration:
Input Signal Level::
Dimensions (WHD):
Dimension w/o deskstand
Actual visible screen size (WH):
Operating temperature/humidity:
Power Requirements:
Power Consumption:
Rear Terminal Connections:
Net Weight:
Gross Weight:
• 2 built-in speakers provide 3D MTS stereo and superior listening pleasure.
• SRS technology provides surround sound experience.
• Enviromental protection includes power-saving capabilities, and
the unit emits no x-radiation.
• Absence of video oscillations and user selection of color temperature
(9300º, 7500º, 6500º) provides enhanced viewing pleasure.
• Hard anti-glare coating enhances viewing pleasure.
• Composite, S-Video, component, HDMI, DVI, and PC capability
• Top controls for channel up/down, volume up/down, source, menu
• Case made of durable plastic (black color)
• Active matrix technology allows wide viewing angle
• Active matrix technology eliminates distortion
• Built-in removable desk stand included
• Includes built-in power supply 100~200 VAC.
• Wireless remote control works within 30 feet.
• Widescreen 16:9 aspect ratio, 4:3, zoom
Optional Accessories
WM- 4700VT Heavy duty dual arm mount for LCD-4700HD, 200 lbs. limit, 4-way adjustable
WM- 3742 Fixed wall mount bracket
WM -3742
47.0" TFT LCD active matrix
Built-in (24 CCFT)
Composite NTSC/PAL, S-Video, component,
analog RGB, HDMI, DVI
IBM compatible
0.5415(V) x 0.5415(H)mm
16.7M
2,073,600
8/8mS (rising/falling)
10W x 2
10W + 10W
89/89/89/89 degrees
Stripe
1.0V P-P (positive) 75 Ohm
1165 x 870 x 340mm / 45.9" x 34.3" x 13.4"
1165 x 830 x 130mm / 45.9" x 32.7" x 5.1"
1018 x 572mm / 42.6" x 22.5"
50 ~ 104°F / 10 ~ 40°C, 20% ~ 90% humidity
100 ~ 240 VAC , 50/60 Hz
236 W (max)
[RCA video IN and RCA R/L IN audio jack] x 2
S-Video IN jack x 2, [RCA Y/Pb/Pr inputs & R/L audio inputs] ,
[RCA Y/Cb/Cr & R/L audio inputs]
RCA audio R & L output, PC audio IN jack,
15-pin D-sub, AC IN, 9-pin RS-232,
HDMI, DVI
80.9 lbs. w/o desk stand
100.4 lbs.
LCD-4700HD
Active Matrix 47" Color LCD HD Monitor
1319 Dexter Ave. N • Ste. 020 • WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
E-mail: [email protected]
http://www.totevision.com
The Biggest Thing
in LCD HD Monitors
• True HD displays 1080p/i without down scaling.
(also supports 480p/i, 576p/i, 720p)
• RS-232 feature allows external devices to
control the monitor through the serial port.
Resolution:
Brightness rating:
Contrast Ratio:
1920 (H) x 1080 (V) dots
550 cd/m² (Nit)
1600:1
with
RS-23
2 and
HDMI
& DVI
P. 2
Specifications subject to change without notice 50K ©2008 ToteVision
• PIP: Picture in picture capability
