Tote Vision LCD-2300HD - Manual

Optional Accessories
Display:
Back Light:
Input Signal:
C compatibility:
Dot Pitch:
Colors:
Contrast Ratio:
Number of Pixels:
Response Time:
Audio output:
Speakers:
Viewing angle L/R/T/B:
Pixel Configuration:
Input Signal Level:
Dimensions (WHD):
Dimensions w/o deskstand (WHD):
Actual visible screen size (WH):
Operating temperature/humidity:
Power Requirements:
Power Consumption:
Rear Terminal Connections:
Net Weight:
Gross Weight:
23.0" TFT LCD active matrix
Built-in (12 CCFT)
Composite NTSC/PAL, S-Video
component, analog RGB, HDMI, DVI
Has digital RGB
IBM compatible
0.39(V) x 0.39(H)mm
16.7M
400:1
983,040
15/10mS
10W x 2
10W + 10W
85/85/85/85 degrees
Stripe
1.0V P-P (positive) 75 Ohm
720 x 475 x 240mm / 28.3" x 18.7" x 9.4"
720 x 413 x 81mm / 28.3" x 16.3" x 3.2"
499 x 299mm / 19.6" x 11.8"
50 ~ 104°F / 10 ~ 40°C, 20% ~ 90% humidity
12VDC, 10A
120 W (max)
[RCA video IN and RCA R/L IN audio jack] x 2
S-Video IN jack x 2, [RCA Y/Pb/Pr inputs & R/L audio inputs] ,
[RCA Y/Cb/Cr & R/L audio inputs]
RCA audio R & L output, PC audio IN jack,
15-pin D-sub, AC IN, 9-pin RS-232,
HDMI, DVI
11.58 kg. / 25.5 lbs.
14.56 kg. / 32.8 lbs.
Active Matrix 23" Color LCD HD Monitor
The Biggest Thing in
LCD HDTV Monitors
1319 Dexter Ave. N • Ste. 020 • WA 98109
Tel: 206-623-6000 • FAX: 206- 623-6609
E-mail: [email protected]
http://www.totevision.com
LCD-2300HD
with
RS-232
and HDMI &
DVI
PLT-2300 VESA conversion plate (for landscape & portrait)
WM-3018VT Fixed wall mount bracket
WM-4200VT 4-way pan/tilt wall mount bracket (order w/ PLT-2300)
WMC-2342
Ceiling mount (order w/ PLT-2300)
WM-3018VT
P. 6
Specifications subject to change without notice 50K ©2008 ToteVision
WM-4200VT
• HD compatible (supports 480p/i, 720p, 1080i)
• RS-232 feature allows external devices to
control the monitor through the serial port.
Resolution:
Brightness rating:
Contrast Ratio:
1366 (H) x 768 (V) dots
500 cd/m² (Nit)
400:1
• PIP: Picture in picture capability
• 2 built-in speakers provide 3D MTS stereo and superior listening pleasure.
• Environmental protection includes power-saving capbilities, and
the unit emits no x-ray radiation.
• Absence of video oscillations and anti-reflective hard coating
provides enhanced viewing pleasure.
• Composite, S-Video, component, DVI, RS-232, and PC capability
• Case made of durable plastic (silver color)
• Active matrix technology allows wide viewing angle
• Active matrix technology eliminates distortion
• Built-in removable desk stand included
• Includes switching power supply 100-240VAC, 50/60 Hz
• Closed-caption and V-chip features
• Wireless remote control works within 30 feet.
• Widescreen 16:9 aspect ratio, 4:3, zoom
• 3D-comb filter
• Response time: 15/10ms (rising/falling)
