At A Glance
1740A/1750A Series Waveform/Vector Monitor User Manual
2-7
OVERLAY
OVERLAY
provides an overlaid display of all se-
lected inputs.
MENU
Push the desired menu button to enter that menu and enable
the associated functions. Push the button again to exit the
menu and disable the function. Refer to page 3-5 for more
information about using menus.
H
FILTER
allows choice of flat or filtered display of the
waveform signal.
H
CURSOR
enables timing cursors, voltage cursors,
and markers for the waveform display. Polar cursors
and markers are available for the vector display.
H
LIN SEL
allows the selection of a single line or group
of lines for display.
H
PRESET
allows the user to store and recall up to 9
front-panel setups. One additional recall is factory
pre-programmed. Presets one through eight can also
be accessed remotely.
H
CONFIG
allows the user to configure several operat-
ing parameters, such as input coupling, dc restorer
speed, and internal reference designation.
H
GAIN
provides selection of
X1
,
X5
,
X10
, and variable
gain.
H
CRT
menu allows adjustment of CRT focus, signal
intensity, and trace rotation.
H
CLEAR MENU
turns off the selection portions of the
menu readout. When
CLEAR MENU
has been used to
clear a menu readout, push the menu button once to
reinstate the readout, and once again to exit the
menu.
