Appendix A: Performance Specification
A-7
1740A/1750A Series Waveform/Vector Monitor User Manual
Table A- 4: Measurement Cursors
CATEGORY DESCRIPTION
Waveform Accuracy Req: Voltage: 0.5%
Timing: 0.5%, for line rate sweeps
RI: Typically 0.5% for field rate sweeps
Vector Accuracy Req: Gain:
±1.5%
Phase:
±1°
RI: Measured with respect to the Color
Bar signal
Table A- 5: RGB/YRGB
CATEGORY DESCRIPTION
RGB/YRGB Req: Staircase input gain: 0.8 V/division
±10%
RI: RGB Sweep Length:
1 Field
≈30% of normal
1 Line
≈ 30% of normal
RI: YRGB Sweep Length:
1 Field
≈ 25% of normal
1 Line
≈ 25% of normal
RI: Maximum staircase operating signal: DC
signal plus peakacnotto exceed --12 V
to+12 V. Line or field rate sweep.
RI: Peak-to-peak acsignal not to exceed
12 V.
RI: Sweep Repetition Rate: Field or line rate
of displayed video or external
sync signal as selected by the front-
panel sweep selection.
