1740A/1750A Series Waveform/Vector Monitor User Manual
1-1
Product Description
The 1740A/ 1750A--Series are combination waveform/vector
monitors in half-rack size packages. The 1740A--Series
provides all basic waveform monitor and vectorscope func-
tions; the 1750A--Series provides the same functions with
SCH measurement capabilities added. The following products
are available:
1740A / 1750A
NTSC
1741A / 1751A
PAL
1745A / 1755A
NTSC / PAL (dual-standard)
Applications
Typical applications for these monitors include video signal
monitoring in camera control units, VTR bridges, production
switcher consoles, mobile vans and field production systems.
The 1740A--Series is well-suited for portable applications
where a small, lightweight monitor is needed, and SCH
capability is not required. It is appropriate for many VTR
bridge applications, providing remote control and 90/100 Hz
sweeps for D-2 servo observation.
The 1750A--Series is useful in the composite edit suite,
providing all 1740A--Series features, plus the Tektronix polar
SCH display to match color subcarrier-to-horizontal sync
timing and color framing among edit sources.
