www.ti.com

Programming the TMS320DM642

Table 16. Decoder 3 Input Format Register

Address

06h

Default

01h

7

6

5

4

3

2

1

0

Reserved

Input Color Standard

Input Color Standard

Bit 2

Bit 1

Bit 0

NTSC

0

0

0

(B, D, G, H, I, N) PAL

0

0

1

(default)

Reserved

. . .

Table 17. Decoder 4 Input Format Register

Address

07h

Default

01h

7

6

5

4

3

2

1

0

Reserved

Input Color Standard

Input Color Standard

Bit 2

Bit 1

Bit 0

NTSC

0

0

0

(B, D, G, H, I, N) PAL

0

0

1

(default)

Reserved

. . .

Table 18. LED Control Register

Address

08h

Default

00h

7

6

5

4

3

2

1

0

Reserved

LED 7 Status

LED 6 Status

LED 5 Status

LED 4 Status

LED 3 Status

LED 2 Status

LED 1 Status

LED (1–7) Status

= 0 (LED off)

= 1 (LED on)

Table 19. Flash Major Version Register

Address

09h

Default

01h

7

6

5

4

3

2

1

0

Flash Major Version

Table 20. Flash Minor Version Register

Address

0Ah

Default

00h

7

6

5

4

3

2

1

0

Flash Minor Version
