SDLT 600 Product Manual Appendix A: Super DLTtape I and Super DLTtape II Data Cartridges
81-81184-02 REV A01 March 2004 A-5
5. Refer to Figure A-3 and check the reel lock openings to ensure the small plastic tabs inside are
partially visible. The reel locks are black. The reel locks can break if you drop the data cartridge. If
the reel lock tabs are not visible, do not use the data cartridge.
Figure A-3. Super DLTtape II Data Cartridge Reel Locks
6. Once again, look at the end of the data cartridge, holding it as shown in Figure A-4 .
Figure A-4. Opening the Super DLTtape II Data Cartridge Door
Reel Lock
Reel Lock
Tab in the door pivot notch
