Table 4-5 on, Table 4-6 on – Tandberg Data SDLT 600 User Manual
Page 64
Configuring and Installing an Internal Tape Drive with SCSI Interface
SDLT 600 Product Manual
4-16
March 2004
81-81184-02 REV A01
+C/D
28
62
-C/D
+REQ
29
63
-REQ
+I/O
30
64
-I/O
+DB(8)
31
65
-DB(8)
+DB(9)
32
66
-DB(9)
+DB(10)
33
67
-DB(10)
+DB(11)
34
68
-DB(11)
Table 4-5.
4-Pin Power Connector Pin Assignments
Pin Number
Signal Name
1
+12 VDC
2
Ground (+12V return)
3
Ground (+5V return)
4
+5 VDC
Table 4-6.
8-Pin Loader Connector Pin Assignments
Signal Name
Pin Number
Pin Number
Signal Name
Ground
1
5
SEND_TO_LOADER_H
REC_FROM_LOADER_H
2
6
SEND_TO_LOADER_L
REC_FROM_LOADER_L
3
7
Ground
Ground
4
8
LOADER_PRESENT_L
Table 4-4.
MSE LVD Mode SCSI Connector Pin Assignments (Continued)
Signal Name
Pin Number
Pin Number
Signal Name
