S Y S T E M S E T T I N G
P L A Y D I S K A L L
H D R E M A I N I N G T I M E 0 H
B U Z Z E R O N
I / O T E R M I N A L M O D E
C T R L O U T T E R M I N A L
S E C U R I T Y S E T T I N G
C A M E R A P R E S E T S E T T I N G
C A M E R A M O D E L T O A – A
C A M E R A B I T R A T E 3 8 4 0 0 b p s
R S 2 3 2 C B I T R A T E 3 8 4 0 0 b p s
R S 2 3 2 C F L O W C T R L O F F
R S 2 3 2 C R E S P O N S E O N
C O N T R O L L E R B I T R A T E 3 8 4 0 0 b p s
C O N T R O L L E R R E S P O N S E O N
D V R – I D 1
L A N G U A G E S E L E C T I O N E N G L I S H
A L L
Item
PLAY DISK
Description
Plays back the images stored on the connected hard disks in
order.
Selection
ALL EXTENDED
MIRROR HDD1 / HDD2
HD REMAINING TIME In “Overwrite Protection” mode, when the remaining recording
time is shorter than the preset remaining time, the disk space
indicator flashes. 0 - 1 - 999 hours
I/O TERMINAL MODE For settings, refer to p. 94 ; I/O terminal mode setting.
CTRL OUT TERMINAL For settings, refer to p. 95 ; Control output terminal setting.
SECURITY SETTING For settings, refer to p. 96 ; Security setting.
BUZZER ON: Buzzer sounds when Priority or Alarm Event Recording
begins, or when the failure is detected.
OFF: Buzzer does not sound.
ON: Performs RS-232C flow control.
OFF: RS-232C flow control not performed.
ON / OFF
RS232C BIT RATE Set the RS-232C’s bit rate. 9600 bps / 19200 bps /
38400 bps
CAMERA BIT RATE Set the control camera’s bit rate.
TOA-A: 9600bps / 19200 bps / 38400 bps
TOA-B: 9600bps / 19200 bps / 38400 bps
BOSCH: 2400 bps / 9600 bps
PELCO-D: 2400 bps
2400 bps / 4800 bps /
9600 bps / 19200 bps /
38400 bps
RS232C FLOW CTRL
CAMERA PROTOCOL
Set the camera protocol to be controlled by the RS-485.
TOA-A: Set to this position when connecting the cameras that
operates using protocol type A.
TOA-B: TOA-A: Set to this position when connecting the
cameras that operates using protocol type B.
BOSCH: TOA-A: Set to this position when connecting the
cameras that operates using BOSCH TC8560/TC700
series protocol.
PELCO-D: Set to this position when connecting the cameras
that operates using Pelco protocol type D.
TOA-A / TOA-B / BOSCH
/ PELCO-D
ON / OFF
RS232C RESPONSE ON: Makes RS-232C communications responses.
OFF: Does not make RS-232C communications responses. ON / OFF
CAMERA PRESET
SETTING For settings, refer to p. 97 ; Camera preset pattern setting.
Set hard disks to be played back.
HDD1: Playback can be performed in order starting from HDD-A,
-C, -E, and -A ….
HDD2: Playback can be performed in order starting from HDD-B,
-D, -F, and -B….
* 1
27. SYSTEM SETTING
Settings can be performed for hard disks to be played back by
the Digital Video Recorder, hard disk remaining time, and
buzzer ON/OFF. It is also possible to set cameras, PCs
(RS232C) and remote controller communications specifications,
etc.
