ASSEMBLY
Assembly Section 2-33
4WD FRONT WHEEL ADJUSTMENT
In order to prevent interferences with mounted equipment, the front wheels on
a 4WD T6000 tractor will have to be adjusted to be approximately 68” center to
center distance (see illustration below). For tractors with mounted loaders, that
distance should be approximately 76”. Double check the wheel spacing after
adjustment by oscillating and turning the tires fully for interference
..
(ASM-NH-0069)
4WD FRONT AXLE STOPS
In order to prevent interferences with mounted equipment, the front axle on a
4WD tractor with wheels larger than 13.6 X R24 will have to be limited. On each
side of the front axle the following procedure must be followed.
The existing spacer and capscrews will need to be removed and a new Tiger
Spacer (p/n 06401546) will need to be added. Sandwich the Tiger Spacer
between the tractor and the existing spacer. The capscrews which were removed
will need to be replaced by two longer Tiger Capscrews (p/n 06530105).
After adding the Tiger Spacer to each side, double-check the adjustment by
oscillating and turning the tires fully for interference . (ASM-NH-0077)
