Data Calls
1. The airborne modem should be configured with its “Re-dial”
function OFF.
2. Connect the modem or PC’s cord to the handset’s RJ-11 jack.
3. Prepare modem to dial telephone number using DTMF tones.
4. Press “4” (Modem) on the handset and command the modem to dial.
5. When the call is connected, place the handset in its holder.
6. Press “End Call” to end the connection.
B2. Fax and Data Calls with a CDBR-2 Data Station
Sending a Fax
1. If using a fax machine, insert the document to be sent into the
feeder.
2. Establish the fax call using the PC or fax machine per
manufacturer’s instructions.
Receiving a Fax
1. No interaction is needed.
Note: The ground party dials the airborne station number and the fax is received
automatically. For more detail, see Section II, E2.
Data Calls
1. Connect the Modem or PC’s cord to the CDBR-2’s RJ-11 jack.
2. Configure the Modem to dial using DTMF tones.
3. Establish the modem call using the PC per the software instructions.
Note: For more information on data calls, refer to Section II, F.
