B. Placing/Receiving Fax and Data Calls
B1. Fax and Data Calls with a C-2000 Handset
Sending a Fax
1. Plug fax machine or PC into Handsets / Remote Handset data port.
2. If using a fax machine, insert document into the feeder.
3. Take handset off-hook and verify dial tone.
4. Establish a fax mode call by pressing “3” (Fax) on the C-2000 hand-
set.
5. On the fax machine or PC enter phone # and press “Start/Transmit.”
6. After the fax call is connected, the handset may be placed in its
holder.
7. At the completion of the call, press “End Call” to terminate the con-
nection.
Note: See Section II, E1 for more information.
Receiving a Fax
1. The ground party calls the handset that the airborne fax machine is
connected to.
2. The airborne party answers the call, using the C-2000 handset which
is connected to the fax machine.
3. On the C-2000 handset, inform the ground party that you are going
to put the call on hold to switch to fax mode. Put the call on hold by
pressing “+” (Put Call on Hold), then immediately switch to fax
mode by pressing “3” (Fax).
4. Take the fax machine handset off-hook (either by lifting its attached
telephone handset or switching the RJ-11 hook switch to the off-
hook mode).
5. The ground party presses “Start/Transmit” on their fax machine.
6. The airborne party presses “Start/Transmit” on their fax machine.
7. At the completion of the call, press “End Call” to terminate the con-
nection. The connection will be terminated automatically if the
ground fax machine hangs up first.
NOTE 1: For Manual and Polling Receive operations, please see Section II, E1.
NOTE 2: The airborne fax machine should be configured with redial function off.
