3 - 12

3.3.7

Paper Holder

(1) Dismount the upper cover assy. (See Section 3.3.4.)

(2) Dismount paper holder

1

.

(3) Unlock and dismount paper guide (L)

2

and paper guide (R)

3

.

(4) Remove the claw and dismount hopper spring

4

.

(5) Remove the claw and dismount stopper spring

5

.

4

5

3

1

2
