Table 8-2 Base Frame Unit
No.
Part Name
Part No.
Q'ty
Remarks
1
Base Frame Assy
2PP4083-1502G1
1
2
High-Voltage Power Supply Board
4YA4130-1024G1
1
3
Paper Sensor E
3PP4083-1191P1
2
4
Friction Pad
4PB4083-1245P1
1
5
Separator Guide
3PP4083-1244P1
1
6
Compression Spring S
4PP4083-1246P1
1
7
Toner Sensor Assy
3PA4083-1193G1
1
8
Pulse Motor
4PB4083-1172P1
1
9
Ep Unit
1
Consumable
10
Toner Cartridge Unit
1
Consumable
11
Hopping Roller
4PB4083-1129P1
1
12
Roller Holder (Hopping Roller)
3PP4083-1128P1
1
13
Magnet H (Hopping Shaft)
3PB4083-1127P1
1
14
Hopping Shaft Assy
3PA4083-1133G1
1
15
Knock Pin
NK2-10-SUS
1
16
Idle Gear R
4PP4083-1143P1
1
17
Idle Gear 2R
3PP4083-1184P1
1
18
Gear R
3PP4083-1142P1
1
19
Idle Gear M
3PP4083-1181P1
1
20
Earth Plate A
3PP4083-1189P1
1
21
Side Plate M
3PP4083-1188P1
1
22
Idle Gear P
3PP4083-1182P1
2
23
Idle Gear 3R
3PP4083-1183P1
1
24
Tension Plate
4PP4083-1165P1
1
25
Idle Gear Heat
3PP4083-1185P1
1
26
Idle Gear E (A)
4PP4083-1186P1
1
27
Idle Gear E (B)
3PP4083-1187P1
1
28
Drive Shaft E (Eject)
3PP4083-1170P1
1
29
Eject Roller
40074601
2
30
Resist Bearing
3PP4083-1141P1
4
31
Resist Roller
3PB4083-1140P1
1
Resist Roller
40457001
1
For China
32
Tension Spring
4PP4083-1252P1
1
33
Gear T
3PP4083-1151P1
1
