2 - 8
Figure 2-3 Layout Drawing of Electro-Photographic Processor
Exit roller
Heat roller (ø 19.910)
6.85
10
OFF
ON
26.50
Outlet sensor
Cleaning roller
(ø 9.000)
Charge roller
(ø 9.000) 6.77
LED head
Drum roller (ø 16.000)
Developing roller
(ø 14.000)
17.23
12.72
23.18
20.32
64.60
Single tray
Transfer roller
(ø 15.000)
Hopping roller
OFF
32.00
10
Tray printing
10
ON
OFF
Manual feed sensor
Manual printing
Feed roller
Paper sensor
