Parts Catalog 7-7
24xx
Asm-
Index Part
Number
Description
2 - 1 12G3841 Carrier Roller Set
2 12G3894 Printhead Assembly (2480, 2481)
2 12G3895 Printhead Assembly (2490, 2491)
3 12G3838 Carrier Unit (2480)
3 12G3837 Carrier Unit (2481)
3 12G3840 Carrier Unit (2490)
3 12G3839 Carrier Unit (2491)
4 12G3889 Cable, Printhead (2480)
4 12G3888 Cable, Printhead (2481)
4 12G3891 Cable, Printhead (2490)
4 12G3890 Cable, Printhead (2491)
5 12G3942 Kit, Pull Tractor Actuator
6 12G3896 Springs, Parts Packet
7 12G3836 Kit, ESD Ground (2490, 2491)
7 12G3887 Kit, ESD Ground (2480, 2481)
8 12G3907 Screws, Washers and Clips, Parts Packet
9 12G3931 Kit, Head Gap Adjustment
10 12G3884 Damper, Frame Assembly
11 12G3905 Gears and Bushings, Parts Packet (248X)
11 12G3906 Gears and Bushings, Parts Packet (249X)
12 12G3834 Sub Frame, Right Side
13 12G3898 Cam, Release Slider and Sub Slider
14 11A3274 Gear, Idler (2480, 2481)
14 11A3275 Gear, Idler (2490, 2491)
15 12G3897 Lever, Paper Select Lever
16 12G3819 Frame, Right Side
17 12G3932 Holder, Lower Pinch Roller Shaft, Right
18 12G3949 Guide, ASF/DTR, Right
19 12G3823 Roller, Lower Feed (2480, 2490)
19 12G3822 Roller, Lower Feed (2481, 2491)
20 12G3835 Roller, Lower Pinch (2480, 2490)
20 12G3943 Roller, Lower Pinch (2481, 2491)
21 12G3900 Shaft, Carrier (2480, 2490)
21 12G3901 Shaft, Carrier (2481, 2491)
