5-4 Service Manual
24xx
Logic Board - Parallel Interface Cable (9w & 24w)
Connector Pin # Signal Pin # Signal
CN11
1 -Strobe 19 Signal Gnd
2 Data 0 20 Signal Gnd
3 Data 1 21 Signal Gnd
4 Data 2 22 Signal Gnd
5 Data 3 23 Signal Gnd
6 Data 4 24 Signal Gnd
7 Data 5 25 Signal Gnd
8 Data 6 26 Signal Gnd
9 Data 7 27 Signal Gnd
10 -Acknlg 28 Signal Gnd
11 Busy 29 Signal Gnd
12 PE 30 Signal Gnd
13 Select 31 -INIT
14 -AUTFED 32 -ERROR
15 NC 33 Signal Gnd
16 Signal Gnd 34 NC
17 Chassis Gnd 35 +5 V dc
18 +5 V dc 36 -SELIN
