Connecting to the RS-232C Port at the Host Section 4-1
Check the required components and prepare them in advance.
Note After connecting a communications cable, always secure it with the screws.
OMRON Cables with Connectors
When a connection is made at serial port A in other than the memory link
method, OMRON cables with connectors shown below are available.
Name Model Remarks Delivered with
Connector XM2A-0901 9-pin
Made by OMRON
CS-series CS1G/CS1H/
CS1D,
CJ-series CJ1G/CJ1H/
CJ1M,
C-series CQM1,
C200HS,
C200HX/HG/HE(-Z)E,
CVM1/CV-series CPU
Units
CV500-LK201
XM24-2501 25-pin
Made by OMRON
C500-LK203
CV500-LK201
C200H-LK201-EV1
DB-25P 25-pin
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
Connector
hood XM2S-0911 9-pin
Made by OMRON
C-series CQM1,
C200HS,
C200HX/HG/HE(-Z)E,
CVM1/CV-series CPU
Units
CV500-LK201
XM2S-0913 9-pin
Made by OMRON
XM2S-0911-E 9-pin
Made by OMRON CS-series CS1G/CS1H/
CS1D,
CJ-series CJ1G/CJ1H/
CJ1M
XM2S-2511 25-pin
Made by OMRON C500-LK203
CV500-LK201
C200H-LK201-EV1
DB-C2-J9 25-pin
Made by JAE
3G2A5-LK201-EV1
3G2A6-LK201-EV1
Cable AWG28
×5P
IFVV-SB
Multi-core shielded cable
Made by Fujikura, Ltd.
CO-MA-VV-SB
5P
×28AWG
Multi-core shielded cable
Made by Hitachi Cable,
Ltd.
Model Cable Length Connector Specification
XW2Z-200S 2 m 9-pin ⇔ 25 pin
XW2Z-500S 5 m
XW2Z-200T 2 m 9-pin ⇔ 9-pin
XW2Z-500T 5 m
