285
Model List
Appendix J
RS-232C/RS-422A Adapter
RS-232C Adaptor, RS-422A Adaptor
Related Parts and Equipment for PT
Reference: The Support Tool indicated above includes the system installer and the standard system programs
(Ver. 3.
@/Ver. 4.@) for the NT31, NT31C, NT631, and NT631C. System programs for the earlier
NT30/620 PTs are also included.
Cables with Connectors for PT
↔ PLC/NT-AL001
Note The following PLCs can supply +5 V: C200HX/HG/HE(-Z)E, CQM1H, CPM2A, CPM2C, CS1G/H/D, and
CJ1G/H/M.
Model
Specification
NT-AL001
RS-232C: 9-pin connector
RS-422A: 8-pin terminal block
Model
Specification
CPM1-CIF01
Links the RS-232C port of an NT631/NT631C and the peripheral port of a CPM1,
CPM2A, CPM2C, or SRM1 (compatible with host link, and NT Link (1:1))
CPM1-CIF11
Links the RS-422A port of an NT631/NT631C and the peripheral port of a CPM1,
CPM2A, CPM2C, SRM1 (compatible with host link)
Name
Model
Remark
Support Tool*
NT-ZJCAT1-EV4
Compatible with PC/AT personal computers
For Windows 95/98/NT4.0/2000/XP (English version)
CD-ROM
Options
NT631C-CFL01
Replaceable backlight (for NT631C-ST151
@-EV1)
NT631C-CFL02
Replaceable backlight (for NT631C-ST141
@-EV1)
NT610C-KBA04
Reflection suppressing protective sheet for NT631/NT631C
NT625-KBA01
Chemical-resistant cover for NT631/NT631C
NT-MF261
Memory Unit for NT631/NT631C
3G2A9-BAT08
Spare battery
Model
Cable Length
Applicable Units
Communications Method
Specification
XW2Z-200S
2 m
Host Link Units with a 25-pin con-
nector
Serial port A host link
(RS-232C only)
9-pin
↔ 25-pin
XW2Z-500S
5 m
XW2Z-200T
2 m
Host lInk Units with a 9-pin con-
nector
Serial port A host link, NT link
(1:1) (RS-232C only)
9-pin
↔ 9-pin
XW2Z-500T
5 m
XW2Z-S002
2 m
Personal computer with a 9-pin
connector
Serial port A for using NT Sup-
port Tool
9-pin
↔ 9-pin
