184
Setting the Bar Code Reader Input Function Section 6-10
6-10 Setting the Bar Code Reader Input Function
The NT631/NT631C has a bar code reader input function which allows a bar
code reader to be connected and bar code data to read as character strings
into character string input fields.
This section describes the communications conditions for the bar code reader
and the setting method for confirming the input data.
Reference: • For details on bar code reader types and connection methods, refer to 3-4
Connecting a Bar Code Reader in this manual and for details on how to
use a bar code reader refer to 3-7 Input of Numeric Values and Character
Strings in the Reference Manual.
• The bar code reader is connected to serial port A. This means that serial
port B must be used for communications with the host.
Communications Condition Settings for Bar Code Readers
* Default (factory) setting
Setting Item Function Setting Options Page
Data bit length Sets the bit length for the data bits. 7* or 8 bits 186
Stop bit length Sets the stop bit length for the data. 1 or 2* bits 186
Parity bit Sets the parity bit for the data. None, odd, even* 186
Communications
speed Sets the communications speed for the bar code reader 4800, 9600*, or 19200 bps 186
Input method Sets the method for confirming data when it is input to a
character string input field.
Manual: The data is confirmed with a touch switch. The data
can be corrected and character strings can be added.
Auto: The data is automatically confirmed when it is input.
Manual*, Auto 186
