Zs-xrs2 – Omron ZS-MDC User Manual
Page 86
5-10
Section 5
APP
E
NDIX
ZS-MDC
User’s Manual
Section 5
Specifications and External Dimensions
RS-232C Cable for Connecting to a Personal Computer
ZS-XRS2
Item
ZS-XRS2
Applicable controller
ZS Series
Ambient temperature
Operating: 0 to 50°C, Storage: -15 to +60°C (with no icing or condensation)
Ambient humidity
Operating and storage: 35% to 85% RH (with no condensation)
Dialectic strength
1,000 VAC, 50/60 Hz for 1 min
Insulation resistance
100 M (by 500 VDC megger)
Vibration resistance
10 to 150 Hz, 0.7 mm double amplitude, 80 min each in X, Y, and Z directions
Shock resistance
300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Materials
Cable sheath: PVC
Weight
Approx. 50 g
10
1
Fitting
1
2
3
4
5
6 7
8 9
1
NC
2
RD(RXD)
3
SD(TXD)
4
NC
5
SG(GND)
6
NC
7
RS(RTS)
8
CS(CTS)
9
NC
1
NC
2
SD(TXD)
3
RD(RXD)
4
RS(RTS)
5
CS(CTS)
6
NC
7
NC
8
NC
9
SG(GND)
NC
10
Signal Name
Pin No.
Signal Name
Pin No.
Note 1: Connector is socket type.
5
8.70
PVC insulated round cable 3.89 mm dia. core
(conductor cross-section: 0.013 mm
(
2
/insulator diameter: 0.38))
9-pin square connector
p
q
10-pin square connector
2000 150
4
41
5.20
32.20
80 20
(Unit: mm)
