Omron ZS-MDC User Manual
Page 67
Sect
ion 4
APPLICATION SETTING EX
AMPLE
S
Section 4
Measuring Flatness
4-11
ZS-MDC
User’s Manual
Press MENU key - ESC key.
2.
Select [TASK1].
[SENSING]-[CALC]-[CALC]-[MAX-MIN]
3.
Set input A to input I for calculating the
flatness to ON, and other input to OFF.
• To output the judgment result of the operation
[I/O SET]-[I/O SET]-[OUT]
4.
Select [TASK1] so that the judgment on the
flatness measurement can be output.
• To linear-output the operation result
[I/O SET]-[I/O SET]-[ANALOG]
4.
Select [TASK1] so that the flatness
measurement can be linear-output.
The calculation results of each CH can be batch-acquired if you use the communication command.
▲
1
TASK1
3
TASK3
2
TASK2
4
TASK4
▲
1
INPUT A
3
INPUT C
2
INPUT B
▲
1
TASK1
3
TASK3
2
TASK2
4
TASK4
▲
1
TASK1
3
TASK3
2
TASK2
4
TASK4
