Zs-mdc – Omron ZS-MDC User Manual
Page 83

5-7
ZS-MDC
User’s Manual
Section 5
APP
E
NDIX
Section 5
Specifications and External Dimensions
Item
ZS-MDC11
ZS-MDC41
I/O type
NPNtype
PNPtype
No. of samples to average
1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1024, 2048, or 4096
Number of mounted Sensor Heads
Cannot be connected
Connectable version of Sensor Controller Ver2.0 or later
Number of mounted Sensor Controllers
Max. 9
(The Controller Link Unit is needed for gang-mounting.)
Exte
rnal
I/F
Connection method
Serial I/O or connector
Prewired (standard cable length: 2 m)
Serial I/O
USB2.0
1 port, FULL SPEED [12 Mbps], MINI-B
RS-232C
1 port, max. 115200 bps
Output
Judgment output
3 outputs: HIGH/
PASS/LOW
NPN open-collector, 30 VDC, 50 mA
max. residual voltage; 1.2 V max.
PNPopen-collector 50 mA
max. residual voltage;1.2V
max.
Linear output
Selectable from voltage/current
(selected by slide switch on base)
• At voltage output: -10 to +10 V, output impedance: 40
• At current output: 4 to 20 mA, max. load resistance: 300
Input
ZERO reset input
ZERO reset execu-
tion/cancel
ON: Short-circuited with 0V terminal
or 1.5 V max.
OFF: Open (leakage current: 0.1 mA
max.)
ON: Supply voltage short-cir-
cuited or within supply volt-
age -1.5 V
OFF: Open (leakage current:
0.1 mA max.)
Timing input
Sample cycle speci-
fied when hold func-
tion is enabled
RESET input
Reset of hold state
Status indicators
HIGH (orange), PASS (green), LOW (orange),
LDON (green), ZERO (green), ENABLE (green)
Segment display
Main display
8-segment red display, 6 digits
Sub-display
8-segment green display, 6 digits
LCD
16 digits x 2 rows, color of characters: green, resolution per charac-
ter: 5 x 8 pixel matrix
Setting input
Setting keys
Direction keys (UP/DOWN/LEFT/RIGHT), SET key, ESC key,
MENU key, function keys (1 to 4)
Slide switch
Threshold switch (H/L 2-state)
MODE switch (FUN/TEACH/RUN 3-state)
Power supply voltage
21.6 V to 26.4 V (including ripple)
Current consumption
0.5 A max.
Insulation resistance
Across all lead wires and controller case: 20 M (by 250 V megger)
Dialectic strength
Across all lead wires and controller case, 1000 VAC, 50/60 Hz, 1
min
Noise immunity
1500 V peak-to-peak, pulse width 0.1
µs/1 µs, rising edge: 1 ns
pulse
Vibration resistance (destructive)
10 to 150 Hz, 0.7-mm double amplitude, 80 min each in X, Y, and Z
directions
