Sect
ion 4
APPLICATION SETTING EX
AMPLE
S
Section 4
Measuring the Relative Difference between Steps
4-7
ZS-MDC
User’s Manual
• To linear-output the operation result
[I/O SET]-[I/O SET]-[ANALOG]
6.
Select TASK1, TASK2, or TASK3 depending
on the details to be output.
To output judgment on the difference between
point A and point B: Set TASK1 to I/O SET
To output judgment on the difference between
point B and point C: Set TASK2 to I/O SET
To output judgment on the difference between
point C and point A: Set TASK3 to I/O SET
The calculation results of each CH can be batch-acquired if you use the communication command.
▲
1 TASK1
3 TASK3
2 TASK2
4 TASK4
