Connecting with External Devices
Connect commercially available external devices suitable for your situation.
Mixer
Stereo
Headphone
φ3.5 mm
φ3.5 mm
φ3.5 mm
Microphone
φ6.3 mm
Microphone
Instrument
XLR connector
PC
Remote control
To USB terminal
To REMOTE jack
To EAR jack
To XLR/standard phone
combo jack
To MIC jack
CD drive
