Page 30

30
Additional Data
Block Diagram/Effect Connection Procedure
fig.0251
* Wherever a block contains one or more icons, it means that some of the parameters of that block can be controlled using the external
controller(s) that the icon(s) represent(s).
* An EFX effect is placed either before or after the COSM amplifier, depending on the effect selected. WAH is before, and others are placed
after.
TUNER
Acoustic
Guitar
Simulator
EFX
(WAH)
EFX
COSM
AMP
DELAY
REVERB
AMP
Cabinet &
Speaker
Simulator
MANUAL (Knob)
MEMORY
INPUT
Guitar
Input
Select Switch
GK
Acoustic Simulator
On/Off Switch
EXT IN
MASTER
Speaker
Mute Switch
SPEAKER
RECORDING OUT /
PHONES
MIDI IN
Audio Signal
Foot Switch
Expression Pedal
COSM
GUITAR
Control Signal
