12

Settings for the GK Pickup (GK Setup)

The Type of Settings

GK SETTING Settings

You can store three sets of settings in the VGA-3.
This conveniently allows you to prepare separate settings for
a multiple number of guitars equipped with a GK pickup.

fig.0022

1. Rotate [GUITAR TYPE] to select “ST” (GK SETTING).

2. Press a MEMORY button [1]–[3] to select the GK SETTING

set you want to enable (the settings you want to change).

* There is no need to change the settings if you are making them

for the first time or if you are not using multiple GK settings.
In this case, select [1] Set A, the factory default setting.

GK DIRECTION Setting

This sets the direction of the GK pickup's installation.

1. Rotate [GUITAR TYPE] to select

“LP” (GK DIRECTION).

2. Press the MEMORY button [1] or [2] to select the

direction in which the pickup is attached.

fig.0030

* If it is difficult to determine the direction in which the GK

pickup was installed on a GK compatible guitar, try it out
initially at the [1] NORMAL setting.
If there is no response from the meter when you play string 6
during the GK SENS 6 settings (p. 13), but there is a response
when you play string 1, change the setting to [2] REVERSE.

Memory button

Setting

[1]

Set A

[2]

Set B

[3]

Set C

GK DIRECTION
GK PHASE
GK S1/S2
GK SENS 1–6
GK LEVEL

Set C

GK DIRECTION
GK PHASE
GK S1/S2
GK SENS 1–6
GK LEVEL

Set B

GK DIRECTION
GK PHASE
GK S1/S2
GK SENS 1–6
GK LEVEL

Set A

Memory button

Setting

[1]

NORMAL
In this direction, the cable exits on
the side of string 6.

[2]

REVERSE
In this direction, the cable exits on
the side of string 1.

NORMAL

REVERSE

string 6 string 1

string 6 string 1
