Rimage Everest III - Manual (Page 30)

Rimage Everest III printer
24 110875_A
4. Install the new retransfer ribbon.
a. Remove the retransfer ribbon from
the packaging.
b. With the supply roll on the left side,
slide both retransfer rolls under the
retransfer ribbon carrier.
c. Install the supply roll on the left side
of the carrier and snap the roll into
place.
d. Bring the take up roll up and around
the guide rollers and snap the roll into
place.
e. Ensure that the retransfer ribbon is
aligned and straight across all the
ribbon guides.
f. To take up the ribbon slack, turn the
take up roll counterclockwise
5. Reassemble the printer .
a. Slide the retransfer carrier into the
printer.
Supply roll
Take up roll
b. Close latches 1 , 2, and 3.
c. Close the side cover .
6. Power on the printer. The printer is ready.
