2. GENERAL DESCRIPTION
2-1-1) EXTERNAL VIEW OF GENERATOR : OPEN FRAME TYPE
DC TERMINALS
DRAIN PLUG
GROUND TERMINAL
AC RECEPTACLES
DC CIRCUIT BREAKER
FUEL TANK
OIL LEVEL GAUGE
FUEL LEVEL GAUGE
MULTI MONITOR
SPARK PLUG
FRAME
SPECIFICATIONS LABEL
AIR CLEANER
MUFFLER
(EXHAUST OUTLET)
ENGINE SWITCH
TANK CAP
RECOIL STARTER HANDLE
RG2800i / RG3200i
