Subaru Robin Power Products RG2800I User Manual
Page 34
5-3-16 MUFFLER
(1) Loosen the two M8 nuts and remove the muffler.
M8 Flange nut : 2 pcs.
Tools : 12mm Box wrench
(2) Loosen the two M6 bolts and remove the muffler
bracket.
M6 x 23mm Flange bolt : 2pcs.
Tools : 10mm Box wrench
– 31 –
5-3-14 FOAM RUBBER INSULATORS
Remove the foam rubber insulators from the gaps
between frame and fuel tank.
5-3-15 MUFFLER COVER
Loosen the four bolts and remove the muffler cover (L)
pushing it inward.
M6 x 12mm Flange bolt : 4pcs.
Tools :10mm Box wrench
