MIDI implementation
V-Accordion r
131
❍ Effect 3 (Chorus Send Level) (Controller number 93)
❍ Program Change
❍ Channel Pressure
■ System Realtime Messages
❍ Active Sensing
❍ Start
❍ Stop
3. Program change messages
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
vv = Chorus Send Level: 00H~7FH (0~127), Initial value = 00H (0)
Status 2nd byte
CnH ppH
n = MIDI channel number: 0H~FH (Ch.1~16)
pp = Program number: 00H~7FH: program no. 1~128
Status 2nd byte
DnH vvH
n = MIDI channel number: 0H~FH (Ch.1~16)
vv = Channel Pressure: 00H~7FH (0~127)
Status
FEH
Transmitted about every 250ms.
Status
FAH
This message is transmitted when a footswitch of FBC-7 Pedal,
programmed as Start/Stop, is pressed, or when “10.17 Start/
Stop MIDI TX” is used.
Status
FCH
This message is transmitted when a footswitch of FBC-7 Pedal,
programmed as Start/Stop, is pressed, or when “10.17 Start/
Stop MIDI TX” is used.
Bank Select & Program Change TX “STD”
BANK SELECT PROGRAM
CHANGE Section MSB CC00 LSB CC32
0 0 1~14 Treble Registers
0 0 1~7 Bass Registers
0 1 1~7 Free Bass Registers
0 0 1~7 Orch Bass Registers
0 0 1~7 Orch Chord Registers
0 0 1~7 Orch FreeBs Registers
0 0 1~26 Orchestra Registers
0 0 1~80 Sets
BANK SELECT PROGRAM
CHANGE Register MSB CC00 LSB CC32
TREBLE REGISTER RX
-- -- 1 Bassoon
-- -- 2 Bandon
-- -- 3 Cello
-- -- 4 Harmon
-- -- 5 Organ
-- -- 6 Accord
-- -- 7 Violin
-- -- 8 Master
-- -- 9 Musette
-- -- 10 Celeste
-- -- 11 Tremolo
-- -- 12 Clarinet
-- -- 13 Oboe
-- -- 14 Piccolo
ORCHESTRA REGISTER RX
-- -- 1 (assignable)
-- -- 2 (assignable)
-- -- 3 (assignable)
-- -- 4 (assignable)
-- -- 5 (assignable)
-- -- 6 (assignable)
-- -- 7 (assignable)
-- -- 8 (assignable)
-- -- 9 (assignable)
-- -- 10 (assignable)
-- -- 11 (assignable)
-- -- 12 (assignable)
-- -- 13 (assignable)
-- -- 14 (assignable)
-- -- 15 (assignable)
-- -- 16 (assignable)
-- -- 17 (assignable)
-- -- 18 (assignable)
-- -- 19 (assignable)
-- -- 20 (assignable)
-- -- 21 (assignable)
-- -- 22 (assignable)
-- -- 23 (assignable)
-- -- 24 (assignable)
-- -- 25 (assignable)
-- -- 26 (assignable)
BASS REGISTER RX
-- -- 1 2’
-- -- 2 4’
-- -- 3 8-4’
-- -- 4 16’/8’/8-4’/4’/2’
-- -- 5 8’/4’/2’
-- -- 6 16’/8’/8-4’
-- -- 7 16’/2’
FREE BASS REGISTER RX
0 1 1 low
0 1 2 high
0 1 3 low+high
0 1 4 lw+hglow
0 1 5 lwlow+hi
0 1 6 highlw+h
0 1 7 lowhigh
ORCH BASS REGISTER RX
-- -- 1 (assignable)
-- -- 2 (assignable)
-- -- 3 (assignable)
-- -- 4 (assignable)
-- -- 5 (assignable)
-- -- 6 (assignable)
-- -- 7 (assignable)
ORCH CHORD REGISTER RX
-- -- 1 (assignable)
-- -- 2 (assignable)
-- -- 3 (assignable)
-- -- 4 (assignable)
-- -- 5 (assignable)
-- -- 6 (assignable)
-- -- 7 (assignable)
ORCH FREE BASS REGISTER RX
-- -- 1 (assignable)
-- -- 2 (assignable)
-- -- 3 (assignable)
-- -- 4 (assignable)
-- -- 5 (assignable)
-- -- 6 (assignable)
-- -- 7 (assignable)
Bank Select & Program Change Set RX
BANK SELECT PROGRAM
CHANGE Section MSB CC00 LSB CC32
-- -- 1 CONCERTO
-- -- 2 CLASSIC
-- -- 3 JAZZ
-- -- 4 “I” FOLK
-- -- 5 “D” FOLK
-- -- 6 “F” FOLK
-- -- 7 “SP” FOLK
-- -- 8 BallROOM
-- -- 9 BANDNEON
-- -- 10 ALPINE
-- -- 11 CAJUN
-- -- 12 TEX MEX
-- -- 13 OldPARIS
-- -- 14 CiaoROME
-- -- 15 DiatFOLK
-- -- 16 STUDIO
-- -- 17 TRDITION
-- -- 18 BAROQUE
-- -- 19 ROMANTIC
-- -- 20 CONCERTN
-- -- 21 SCOTTISH
-- -- 22 IRISH
-- -- 23 CELTIC
-- -- 24 XLowReed
-- -- 25 HalfVALV
-- -- 26 FUTURE
-- -- 27 MUSETTE
-- -- 28 BASSOON
-- -- 29 MASTER
-- -- 30 EXAMPLES
-- -- 31 FRANCE vX
-- -- 32 FRANCE Ac
-- -- 33 FJAZZ
-- -- 34 “I” SCALA
-- -- 35 BAJAN
-- -- 36 RHYTHM
-- -- 37 ORGAN
-- -- 38 OrPARADE
-- -- 39 ALL ORCH
-- -- 40 V-Set
-- -- 41 WOA1-Ac
-- -- 42 WOA1-Bs
-- -- 43 WOA2-Exp
