67
What knobs do
Common condition
* To return to the standard value (0), hold down the [SHIFT] key and press the [KEYBOARD] button.
Recording condition
* The settings that can be modified will depend on the selected effect type. Refer to “Changing the effect type”
(p. 44).
Others
MODE C1 knob C2 knob C3 knob CUTOFF
knob RESO
knob DECAY
knob [INC]/[DEC]
(DISPLAY=TONE/
TYPE)
LINE IN — — — — — — —
LEAD
Overdrive/
Distortion OSC tune * Drive Tone
Cutoff
frequency Resonance
Filter
envelope
decay time
Tone
Phaser Rate Depth Resonance
Slicer+
Ring mod-
ulator Rate Gate time Ring
frequency
BASS OSC tune * Filter
envelope
depth Accent Cutoff fre-
quency Resonance Filter
envelope
decay time Tone
RHYTHM — — — Bass drum
level Snare drum
level Hi-hat
level Rhythm set
EFFECT
Filter Rate Cutoff
frequency Resonance
— — — Effect type
Isolator Low gain Middle gain High gain
Phaser Rate Depth Resonance
Slicer Rate Gate time Pan
LOOP CTRL — — — — — — Loop
control type
MODE C1 knob C2 knob C3 knob CUTOFF
knob RESO
knob DECAY
knob [INC]/[DEC]
(DISPLAY=TONE/
TYPE)
LINE IN — — — — — — —
LEAD Note Velocity Gate time — — — —
BASS Note Velocity Gate time — — — —
RHYTHM
(TR recording only)
Rhythm
tone Volocity — — — — ---
EFFECT — — * — — — —
LOOP
CTRL Pitch — — Pitch — — — —
Trigger — — Part — — — —
Divide
times 16 — — Position — — — —
C1 knob C2 knob C3 knob CUTOFF
knob RESO
knob DECAY
knob [INC]/[DEC]
Loop edit Pitch Position Length — — — —
Loop pan — — — — — — Pan
