Page 59: Pre l iminar y
VX-3000d Series Installation/Operation Manual
43
PRE
L
IMINAR
Y
RGBHV Source Connections: Connect personal computers and/or other RGB sources
to the HD1, HD2 and/or Component/SCART inputs as shown in Figure 3-17.
Figure 3-17. RGBHV Source Connections
or
Computer
RGB Camcorder
BNC-to-RCA
adapter
Green
Blue
Red
H-Sync
V-Sync
Green
H-Sync
Blue
V-Sync
Red
