2.1
VX-3000d at a Glance
Figure 2-1 and Figure 2-2 show the key VX-3000d components.
Figure 2-1. VX-3000d Front/Side/Top View
1.
EXHAUST VENT
2.
ZOOM TAB (Standard VX-3000d)
Use this to change the projected image size with a standard VX-3000d. (Use the
remote control unit to adjust the zoom with an VX-3000d Ultra.)
3.
TOP IR SENSOR
