Specifications
VX-3000d Series Installation/Operation Manual 101
PRE
L
IMINAR
Y
7.4
Overall Dimensions –
VX-3000d Ultra Figure 7-2 shows the VX-3000d Ultra dimensions (all dimensions are in inches).
Figure 7-2. Overall Dimensions – VX-3000d Ultra
0
9.8
18.8
14.9
19.7
0 .8
6.3 7.3
.7
.9
.5
5.0
6.8
6.6
9.6
0
2X 1.2
2X 18.5
5.3
14.2
15.3
4.1
5.5
19.7
0 5.1 2X 5.9 2X 15.2 18.1 19.9 21.5 21.3
4X M6 ST
ANDOFFS
CEILING MOUNTING HOLE
