Overview
1.3 External Specifications
Rev.1.0 Feb 6, 2007 1-3
REJ10J0916-0100
1
1.3 External Specifications
Table1.3.1 lists external specifications of M3A-HS86.
Table1.3.1 External Specifications of M3A-HS86
No. Item Content
1 CPU
SH7086
•
Input(XIN) clock : 10MHz
•
Bus clock : 40MHz,max
•
CPU clock : 80MHz,max
•
On-chip memory
Flash memory : 512KB
RAM : 32KB
2
Memory
*M3A-HS86(3.3V version) only
•
SDRAM : 16 Mbytes.(16-bit bus width) 1pc
•
External flash memory enabled to mount
3 Connectors
•
Extension connector (Bus, I/O, VCC, GND)
•
User I/O connector (SH7086’s MTU2 and A/D function pins)
•
Serial port connector (D-sub 9pins)
•
H-UDI connector (36pins)
•
H-UDI connector (14pins)
4 LED
•
POWER LED (1pc.)
•
LED for interrupt switch (1pc.)
•
User LED (7pcs.)
5 Switches
•
Reset switch (1pc.)
•
NMI switch (1pc.)
•
IRQ1 switch (1pc.)
•
DIP switch for system setting (1pc.,4 poles)
•
DIP switch for users (1pc.,4 poles)
6 Package Dimensions
•
Dimensions :100mm x 100mm
•
Mounting form :6-layer, double-side mounted
•
Board configuration :1 board
