Operational Specifications
3.1.6 Extension Connectors (J9-J13)
Rev.1.0 Feb 6, 2007 3-14
REJ10J0916-0100
3
Table3.1.12 lists pin assignments of extension connectors.
Table3.1.12 Pin Assignments of Extension Connectors (J12)
Pin Signal Name Other Connection
1 NC -
2 NC -
3 NC -
4 NC -
5 NC -
6 PE0/DREQ0/TIOC0A/AUDCK H-UDI connector (J1)
7 NC (PE3/TEND1/TIOC0D/AUDATA3 when R68 mounted) H-UDI connector (J1)
8 NC (PE4/IOIS16
__________
/TIOC1A/RXD3/AUDATA2 when R69 mounted) H-UDI connector (J1)
9 NC (PE5/CS6
_______
/CE1B
_________
/TIOC1B/TXD3/AUDATA1(when R70 mounted) H-UDI connector (J1)
10 NC (PE6/CS7
_______
/TIOC2A/SCK3/AUDATA0 when R71 mounted) H-UDI connector (J1)
11 PE7/RXD2/BS
_____
/TIOC2B/UBCTRG
______________
/SSI Extension connector (J11), LED4
12 PE9/TIOC3B/SCK3/RTS3
_________
/TRST
__________
H-UDI connector (J1,J2)
13 PE11/TIOC3D/RXD3/CTS3
__________
/TDO H-UDI connector (J1,J2)
14 PE12/TIOC4A/TXD3/SCS
________
/TCK H-UDI connector (J1,J2)
15 PE13/TIOC4B/MRES
___________
/ASEBRKAK
__________________
/ASEBRK
______________
H-UDI connector (J1,J2), MRES switch *2
16 PE14/WRHH
___________
/ICIOWR
_____________
/AH
_____
/DQMUU/DACK0/TIOC4C LED5
17 PE15/CKE/DACK1/TIOC4D/IRQOUT
_____________
-
18 PA15/CK
Extension connector (J12), SDRAM *1 ,
Clock buffer *2
19 PA16/WRHH
___________
/ICIOWR
_____________
/AH
_____
/DQMUU/CKE/DREQ2/AUDSYNC
________________
H-UDI connector (J1)
20 GND -
Notes *1: M3A-HS86 (3.3V version) only.
*2: Not mounted.
