Operational Specifications
3.1.6 Extension Connectors (J9-J13)
Rev.1.0 Feb 6, 2007
3-15
REJ10J0916-0100
3
Table3.1.13 lists pin assignments of the extension connectors.
Table3.1.13 Pin Assignments of the Extension Connectors (J13)
Pin Signal
Name
Other Connection
1
5V -
2
5V -
3
PA17/W AIT
_________
/DACK2 -
4
PD31/D31/TIOC3AS/ADTRG
____________
-
5
PD30/D30/TIOC3CS/IRQOUT
______________
-
6
PD29/D29/C S3
_______
/TIOC3BS -
7
PD28/D28/C S2
_______
/TIOC3DS -
8
PD27/D27/DACK1/TIOC4AS -
9
PD26/D26/DACK0/TIOC4BS -
10
PD25/D25/DREQ1/TIOC4CS -
11
PD24/D24/DREQ0/TIOC4DS -
12
PD23/D23/IRQ7/AUDSYNC
_________________
-
13
PD22/D22/IRQ6/TIC5US/AUDCK
Extension connector (J7)
14
PD21/D21/IRQ5/TIC5VS
Extension connector (J7)
15
PD20/D20/IRQ4/TIC5WS
Extension connector (J7)
16
PD19/D19/IRQ3/POE7
_________
/AUDATA3 -
17
PD18/D18/IRQ2/POE6
_________
/AUDATA2 -
18
PD17/D17/IRQ1/POE5
_________
/AUDATA1 -
19
PD16/D16/IRQ0/POE4
_________
/AUDATA0 -
20
GND
-
21
PE2/DREQ1/TIOC0C LED3
22
PE1/TEND0/TIOC0B LED2
23
PA14/RD
_____
Flash
memory
*2
24
PD15/D15/TIOC4DS SDRAM
*1
,
,
Flash memory
*2
25
PD14/D14/TIOC4CS SDRAM
*1
, Flash memory
*2
26
PD13/D13/TIOC4BS SDRAM
*1
, Flash memory
*2
27
PD12/D12/TIOC4AS SDRAM
*1
, Flash memory
*2
28
PD11/D11/TIOC3DS SDRAM
*1
, Flash memory
*2
29
PD10/D10/TIOC3CS SDRAM
*1
, Flash memory
*2
30
PD9/D9/TIOC3BS SDRAM
*1
, Flash memory
*2
31
PD8/D8/TIOC3AS SDRAM
*1
, Flash memory
*2
32
PD7/D7/TIC5WS SDRAM
*1
, Flash memory
*2
33
PD6/D6/TIC5VS SDRAM
*1
, Flash memory
*2
34
PD5/D5/TIC5US SDRAM
*1
, Flash memory
*2
35
PD4/D4/TIC5W SDRAM
*1
, Flash memory
*2
36
PD3/D3/TIC5V SDRAM
*1
, Flash memory
*2
37
PD2/D2/TIC5U SDRAM
*1
, Flash memory
*2
38
PD1/D1 SDRAM
*1
, Flash memory
*2
39
PD0/D0 SDRAM
*1
, Flash memory
*2
40
GND
-
Notes *1: M3A-HS86 (3.3V Version) only.
*2: Not mounted.
